Product Details
＋
FEATURES
- Dual-band AC1900 up to 1.9 Gbps
- Up to 600 Mbps for the 2.4 GHz radio and up to 1300 Mbps for the 5 GHz radio
- Dual-core processor
- 3x3 spatial streams
- MU-MIMO technology
- Beamforming technology
- Seamless roaming
- Coverage up to 1,600 sq ft
- One USB 3.0 port (for external USB storage drives)
| Indicator Light | Color | Activity | Description |
| Power | White | OFF | Power OFF |
| Blinking (0.7 Hz) | Booting / system diagnostic test / firmware upgrade | ||
| Blinking (1.67 Hz) | Internet connection error | ||
| Solid | Connected to the internet | ||
| WPS | Green | OFF | No WPS activity |
| Blinking (1.0 Hz) | WPS in progress (up to 2 minutes) | ||
| Blinking (2.0 Hz) | WPS error or session overlap (blinks for 15 seconds and then turns OFF) | ||
| Ethernet (LAN) | Green (right) / Yellow (left) | OFF | No physical link on the port |
| Blinking (4.0 Hz) (Yellow) | Data is transmitting through the port | ||
| Solid (Green) | An ethernet cable is connected to the port | ||
| Internet (WAN) | Green (right) / Yellow (left) | OFF | No physical link on the port |
| Blinking (4.0 Hz) (Yellow) | Data is transmitting through the port | ||
| Solid (Green) | An ethernet cable is connected to the port |
