Product Details
＋
Note: This is a B2B Product
-Prices are indicative and discounts available based on quantities
-Design services available for these systems. Please contact our team for support on , or .
FEATURES:
- 5 Mic & 2 Aux Inputs.
- Built-in MP3 player with remote control for USB, SD/MMC card reader.
- Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the program.
- Line Input for connecting the output from any external mixer or permitting SSA-160DP to be used as a Booster Power Amplifier.
- Resettable circuit breaker for protection against overload and short circuit.
- Instant transfer to DC power (Car Battery) if AC power fails.
- Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.
- 5 LED array for output level monitoring.
SPECIFICATIONS:
Power Output | 220W Max., 160W RMS at 10% THD, 140W RMS at 5% THD, 120W RMS at 2% THD |
Output Regulation | ≤ 2 dB, no load to full load at 1kHz |
Input Channels | 5 × Mic 0.65mV/4.7kΩ, 2 × Aux 100mV/470 kΩ |
Frequency Response | 50-15,000Hz ±3dB |
Signal to Noise Ratio | 60dB |
Tone Controls | Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz |
Output | Preamp 200mV/600Ω, Line 1V/1kΩ |
Speaker Output | 4Ω, 8Ω, 70V & 100V |
Digital Player | MP3 Player with USB, SD and MMC Card Reader |
Power Supply | AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery) |
Power Consumption | AC: 300VA DC: 4A |
Dimensions | W420 × H155 |
